Function and Features：
1、Adopt mature technology PLC control system,operation is stable and high-speed.
2、Using touch-screen control operating system,simple,practical,efficient.
3、Screw adjustment mechanism press bottle move accurately
4、Synchronization chain mechanism ensure labeling smooth.
5、Advanced technology of pneumatic code system.
6、Print the batch number and expiry date clearly.
7、Transmission-type roll label device,make sure the label attached more firmly.
Technical Parameter：
|
Type |
USN-TB-A |
|
Driving Mode |
Servo motor |
|
Operating direction |
Left or Right |
|
Labeling Accuracy |
±1.0mm |
|
Production |
60-100(pcs/min) |
|
Labeling Speed |
≤35(m/min) |
|
Label Specification |
Adhesive sticker, opaque label |
|
The application of bottle |
Outer diameter20-120mm；Height35-250mm |
|
The application of label |
Height20-180mm Length30-300mm |
|
The inner diameter of label roll |
76mm |
|
The outer diameter of label roll |
350mm |
|
The power of motor |
550W |
|
Power |
Single Phase 220V 50/60HZ |
|
Machine size |
1800(L)x700(W)x1270(H)mm |
